Polypropylene (PPH) Drums
| Specification | AGTPP C-250 | AGTPP C-600 | AGTPP C-800 | AGTPP C-1200 | AGTPP C-1500 | AGTPP C-2000 |
|---|---|---|---|---|---|---|
| Shaved WT. Loading (KG) | 250 | 600 | 800 | 1200 | 1500 | 2000 |
| Drum Speed (RPM) | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 |
| Motor Power (HP) | 12.5 | 20 | 25 | 40 | 40 | 50 |
| Drum Diameter (mm) | 2150 | 2500 | 2500 | 3000 | 3000 | 3500 |
| Drum Width (mm) | 1500 | 2000 | 2500 | 2500 | 3000 | 3000 |
| Overall Dimensions (mm) | W2800 D2800 H2700 | W3500 D3200 H3200 | W4000 D3300 H3200 | W4500 D3700 H3600 | W5000 D3700 H3700 | W5000 D4250 H4250 |
Polypropylene (PPH) High Loading Drums (Jumbo Configuration)
| Specification | AGTPP H-300 | AGTPP H-900 | AGTPP H-1100 | AGTPP H-1500 | AGTPP H-2200 | AGTPP H-3000 | AGTPP H-4000 |
|---|---|---|---|---|---|---|---|
| Shaved WT. Loading (KG) | 300 | 900 | 1100 | 1500 | 2000 | 3000 | 4000 |
| Drum Speed (RPM) | 5 - 7 | 5 - 7 | 5 - 7 | 5 - 7 | 5 - 7 | 5 - 7 | 5 - 7 |
| Motor Power (HP) | 10 | 15 | 25 | 30 | 40 | 50 | 50 |
| Drum Diameter (mm) | 2150 | 2500 | 2500 | 3000 | 3000 | 3500 | 4000 |
| Drum Width (mm) | 1500 | 2000 | 2500 | 2500 | 3000 | 3250 | 3500 |
| Overall Dimensions (mm) | W2800 D2800 H2700 |
W3500 D3200 H3200 |
W4000 D3300 H3200 |
W4500 D3700 H3600 |
W5000 D3700 H3700 |
W5250 D4250 H4250 |
W6000 D5000 H5000 |
