Technical Specifications
| Specification / Model | AGTD TD-30 | AGTD TD-60 | AGTD TD-100 | AGTD TD-150 |
|---|---|---|---|---|
| Drying Capacity (KG) | 30 | 60 | 100 | 150 |
| Drum Volume (L) | 615 | 1220 | 2015 | 2900 |
| Dry Speed (rpm/min) | 34 | 34 | 34 | 34 |
| Electrical Heating (KW) | 18KW / 24KW | 27KW / 36KW | 80KW | 96KW |
| Drive Motor (KW) | 0.75 | 1.5 | 2.2 | 3.75 |
| Exhaust Motor Size (KW) | 0.75 | 1.5 | 1.5 * 2 | 1.5 * 3 |
| Door Opening Dia (mm) | 800 | 800 | 1000 | 1000 |
| Weight (Kg) | 575 | 880 | 980 | 1500 |
| Drum Diameter (mm) | 970 | 1220 | 1450 | 1770 |
| Drum Depth (mm) | 830 | 1050 | 1220 | 1220 |
| Cabinet Height (mm) | 1850 | 2150 | 2510 | 2650 |
| Cabinet Width (mm) | 1030 | 1350 | 1620 | 2000 |
| Cabinet Length (mm) | 1300 | 1980 | 1870 | 1970 |
