Stainless Steel Drums
| SPECIFICATION | AGTSS- 7 | AGTSS-18 | AGTSS-30 | AGTSS-40 |
|---|---|---|---|---|
| Shaved WT. Loading (KG) | 7 | 18 | 30 kg | 40 |
| Drum Speed (RPM) | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 |
| Motor Power (HP) | 1 | 2 | 3 | 5 |
| Drum Diameter (mm) | 800 | 1000 | 1200 | 1400 |
| Drum Width (mm) | 400 | 500 | 750 | 750 |
| Overall Dimensions (mm) | W1600 D1000 H1400 | W1700 D1300 H1800 | W1800 D1500 H1700 | W1800 D1700 H1800 |
| Heating Load (kW) | 6 | 9.0 | 12 | 12 |
Polypropylene (PPH) Drums
| Specification | AGTPP-7 | AGTPP-18 | AGTPP-30 | AGTPP-50 | AGTPP-75 | AGTPP-100 |
|---|---|---|---|---|---|---|
| Shaved WT. Loading (KG) | 7 | 18 | 30 | 50 | 75 | 100 |
| Drum Speed (RPM) | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 | 9 - 14 |
| Motor Power (HP) | 1 | 2 | 2 | 3 | 7.5 | 10 |
| Drum Diameter (mm) | 800 | 1000 | 1200 | 1200 | 1550 | 1850 |
| Drum Width (mm) | 400 | 500 | 750 | 900 | 1280 | 1250 |
| Overall Dimensions (mm) | W1600 D1000 H1400 |
W1800 D1200 H1800 |
W1800 D1500 H1800 |
W1800 D1500 H1800 |
W1950 D1900 H2000 |
W1950 D2100 H2100 |
